- IP 65 WATER & DUST PROOF BALANCE
- Premier Class Precision Balance
- - Heavy duty
- - High performance
- - Reliable measurement
-
As heavy-duty high-precision balance with water & dust proof feature, CJ series promises the excellent performance in any environment, dust atmosphere, mist, oil splashes, dark condition... etc. The stainless-steel upper case is resistent to chemical products, and easy to clean.
CJ series provides multi-function & multi-mode measurement and covers the wide weighing range from 220g to 15kg with minimum readability 0.01g.
This is the best solution to your every needs.
Declaration of CE conformity CJ.pdf
High speed response & stable indication
Unique tuning-fork sensing system achieves the high speed response and stable indication necessary for reliable measurement. The fast response ensures the comfortable and efficient operation.
Stainless steel highly resistent to tough conditions
Mirror finished stainless steel housing easy to clean, durable to tough conditions.
Clearly visible back light
Large LCD (18mm height) with blight back light make the weighing operation easy and comfortable even in the dark location.
Low energy-consuming, high portability
Low energy-consuming design allows CJ series to operate for 200 hours with dry-cell battery (when back-lit is OFF). It is very much suitable for mobile use (32-hour operation with dry-cell battery in case of back-lit ON).
Variety of weighing modes & functions for laboratory and industrial use
CJ offers you a variety of weighing modes and functions which can meet wide range of requirements, animal weighing, density measurement, parts counting, comparator, percentage...etc.
Connecting to outside devices
RS232C output is equipped as standard, easy connection to outside devices like PC. Plentiful outputs besides RS232C are available as option (special WP cable option is necessary when CJ should be used with RS232C output as water-proof).
CJ-×××CE stands for EC type approval model
| With EC approval | CJ-220E CJ-220CE |
CJ-320E CJ-320CE |
CJ-620E CJ-620CE |
CJ-820E CJ-820CE |
|---|---|---|---|---|
| Capacity | 220g | 320g | 620g | 820g |
| Readability | 0.01g | 0.01g | 0.01g | 0.01g |
| Non-Linearity *1 | ±0.01g | |||
| Repeatability *2 | 0.01g | |||
| Pan size | 140mm dia. | |||
| Calibration | with external weight | |||
| Weight units *3 | g, ct, oz, lb, ozt, dwt, GN tl (Hong Kong), tl (Singapore, Malaysia), tl (Taiwan), momme, tola | |||
| Dimensions(LWH) | 310×208×87mm | |||
| Weight | Approx. 2.2kg | |||
| With EC approval | CJ-2200E CJ-2200CE |
CJ-3200E CJ-3200CE |
CJ-6200E CJ-6200CE |
CJ-8200E CJ-8200CE |
CJ-15KE CJ-15KCE |
|---|---|---|---|---|---|
| Capacity | 2200g | 3200g | 6200g | 8200g | 15000g |
| Readability | 0.1g | 0.1g | 0.1g | 0.1g | 1g |
| Non-Linearity *1 | ±0.1g | ±1g | |||
| Repeatability *2 | 0.1g | 1g | |||
| Pan size | 190×190mm | ||||
| Calibration | with external weight | ||||
| Weight units *3 | g, ct, oz, lb, ozt, dwt, GN tl (Hong Kong), tl (Singapore, Malaysia), tl (Taiwan), momme, tola | ||||
| Dimensions(LWH) | 310×208×87mm | ||||
| Weight | Approx. 2.7kg | ||||
- e=d for all CE models
- *1 typical value
- *2 standard deviation
- *3 only g, kg &ct are available in CE models.
| CJ-R4 | RS422A output (D-sub 9p) |
|---|---|
| CJ-BZ | Buzzer output |
| CJ-LM | Relay contact (Din 9p) |
| CJ-LS | Full pack (BZ, RS, LM) |
| CJ-BT | Dry-cell battery |
| CJ-WR | Water-proof cable for RS232C output (9PWP-9P) |
| AJUH(S) | Under-weighing hook |
| CJ-AP(S) | Bucket for animal weighing (620g, 820g) |
| CJ-AP(M) | Bucket for animal weighing (2200-6200g) |
| CJ-AP(L) | Bucket for animal weighing (8200g-15kg) |
