- High performance and durability
for everyday laboratory use. - Wide weighing space
Provides a large area for weighing samples. The two-piece sliding door is stored neatly inside the scale, when opened. - Big display
Reading the display is easy with a 18mm high LCD. - ISO/GLP/GMP
Record calibration procedures and results with an optional printer. - One touch calibration
Calibrate the scale with just one touch of calibration key - calibration uses an internal weight. (R type) - CAL adviser
Advises operator when calibration is recommended due to an environmental change (R type) - Easy to clean
Components are easily separable, making it easy to clean inside the glass plural or singular, weighing pan, etc. - One-handed door system
Leaves one hand free when operating the door. For example, if you are right handed, handle your sample with your right hand while opening the right door with your left hand.
- Wide weighing space
| Model | AF-220E | AF-R220E |
|---|---|---|
| With EC approval | AF-220CE | AF-R220CE |
| Capacity | 220g | |
| Readability | 0.0001g | |
| Repeatability | 0.0001g | |
| Non-Linearity | ±0.0003g | |
| Pan size | φ 80mm | |
| Windshield | 3 Sliding-doors | |
| Dimension | 320 × 210 × 335mm | |
| Power source | AC120/230V DC9V | |
| Output | RS-232C, Printer Output | |
| Calibiration | Manual with standard weight | Semi-automatic with internal weight |
| Mode selection | Weighing, counting, percentage, accumulation | |
| Functions | Calendar, Clock / Built-in under hook weighing Calibration weight error setting Calibration of internal weight with standard weight SCS system in counting mode |
|
| Weight | Approx. 5.2kg | Approx. 5.5kg |
